Electronic Oblique Tip Cutter ESD
4570
Description
- for virtually flush cutting of thin, soft wires in places difficult to access, for work with electrostatic endangered components
- extra narrow head, fine bevel, maximum stability under load by additional inductive hardening and box joint, with double opening leaf spring, polished and high gloss gunmetal-finish, with 2-C ESD handles, surface resistance 106-109 Ohm
- cutting edge hardness 61-63 HRC
- ELORA-Chrome-Vanadium 80CrV2 / 1.2235
- DIN ISO 9654, ESD: DIN IEC 614340-5-1
Measurements
| Number | Medium mm / AWG | Soft mm / AWG | Length mm | Weight g |
|---|---|---|---|---|
| 4570-F E 2K | 0,6 / 22 | 0,8 / 20 | 130 | 96 |
