VDE-Voltage Tester, two-pole
564N
Description
- to detect AC voltage between 6V-1000V and DC voltage between 6V-1400V
- optical, audible and vibration alert if life-threatening voltage occurs starting from 35V
- polarity phase indication at DC
- automatic selection of measurement range, 1 pole single phase detection, two-pole 3 phase control
- continuity test 0-200 kOhm (optical and audible)
- Diode test
- FI/RCD-control test (30mA) via two feelers
- white LED metering monitor light
- easily operated click system to adjust the power socket size
- optimum one-hand operation
- special tips also fit to WAGO-clamps
- unscrewable 4 mm test tip adapter and GS 38 test attachments
- non-volatile test tip covers
- black rubber grips
- dust- and water-jet-proof
- CAT IV 1000V according to IEC/EN 61243-3:2014-02 (DIN VDE 0682-401)
- WAGO= reg. Trademark of company WAGO Kontakttechnik GmbH & Co. KG, Minden / Germany
Measurements
| Number | Length mm | Weight g |
|---|---|---|
| 564N | 300 | 320 |
