VDE Single End Ring Spanner, deep cranked
988-...
Description
- 2-colour-multilayer isolation (yellow, red) for easy identification of insulation damages
- VDE insulation up to 1.000V, according to EN 60900/IEC 60900:2004
- tested according to EN/IEC 60900, individually tested with 10.000V and approved for 1.000V
- ELORA Chrome-Vanadium 31CrV3 / 1.2208
Measurements
| Number | Size mm | 1000 V | VDE | GS | Weight g | More |
|---|---|---|---|---|---|---|
| 988-10 | 10 | x | x | x | 80 | PU:6 Length mm:165 |
| 988-11 | 11 | x | x | x | 100 | PU:6 Length mm:175 |
| 988-12 | 12 | x | x | x | 110 | PU:6 Length mm:185 |
| 988-13 | 13 | x | x | x | 120 | PU:6 Length mm:195 |
| 988-14 | 14 | x | x | x | 150 | PU:6 Length mm:200 |
| 988-15 | 15 | x | x | x | 155 | PU:6 Length mm:205 |
| 988-17 | 17 | x | x | x | 180 | PU:6 Length mm:210 |
| 988-19 | 19 | x | x | x | 245 | PU:6 Length mm:230 |
| 988-22 | 22 | x | x | x | 353 | PU:6 Length mm:250 |
| 988-24 | 24 | x | x | x | 357 | PU:6 Length mm:260 |
| 988-27 | 27 | x | - | - | 438 | PU:6 Length mm:280 |
| 988-30 | 30 | x | - | - | 454 | PU:6 Length mm:280 |
| 988-32 | 32 | x | - | - | 580 | PU:6 Length mm:300 |
