Circlip Pliers for external retaining ring
474-A11-41
Description
- for external retaining rings acc. to DIN 471, DIN 983
- jaws bent at 90°, self-opening due to mounted double leaf spring
- chrome plated, polished joint, chequered handles
- ELORA-Chrome-Vanadium 31 CrV 3 / 1.2208
- according to DIN 5254 Form B
Measurements
| Number | For circlips from ... to Ø mm | Length mm | Length inch Inch | Ø Tip mm | Weight g |
|---|---|---|---|---|---|
| 474-A01 | 3-10 | 130 | 5 | 0,9 | 95 |
| 474-A11 | 10-25 | 135 | 5 | 1,3 | 113 |
| 474-A21 | 19-60 | 170 | 7 | 1,8 | 180 |
| 474-A31 | 40-100 | 220 | 9 | 2,3 | 276 |
| 474-A41 | 85-165 | 320 | 13 | 3,2 | 502 |
