Torque Angle Gauges
2184-...
Description
- for controlled screw tightening with fitting torque wrench at specified torque and torque angle
- torque angle from 0 – 360°
- 1/2'' reading accuracy 2 degrees, 3/4'' reading accuracy 5 degrees
- maximum load 1/2'' 390 Nm, 3/4'' 1330 Nm
- with flexible magnetic holder
- square with ball locking device
- attention, do not exceed the maximum torque of the specific torque wrench!
Measurements
| Number | Output male square | Drive female square | Graduation Nm | Ø | Weight g | More |
|---|---|---|---|---|---|---|
| 2184-1 | 1/2" | 1/2" | 20 | 68 | 333 | PU:1 Length mm:360 |
| 2184-2 | 3/4" | 3/4" | 50 | 90 | 865 | PU:1 Length mm:380 |
