Electronic Tungsten Carbide Side Cutter ESD
4630
Description
- for cutting very hard wires which are difficult to access, for all work with electrostatic endangered components
- pointed, narrow head with groove and fine bevel, small version, maximum stability under load by carbide inlay and box joint, with double opening leaf spring, polished and high gloss gunmetal-finish, with 2-C ESD handles, surface resistance 106-109 Ohm
- cutting edge hardness 84-86 HRA
- ELORA-Chrome-Vanadium 80 CrV2 / 1.2235 and special carbide metal
- DIN ISO 9654, ESD: DIN IEC 614340-5-1
Measurements
| Number | Piano mm / AWG | Hard mm / AWG | Soft mm / AWG | Length mm | Weight g |
|---|---|---|---|---|---|
| 4630-F E 2K | 0,4 / 26 | 0,8 / 20 | 1,8 / 13 | 125 | 99 |
