Ring Slogging Spanner, metric
86M-...
Description
- heavy, drop-forged type
- sand-blasted
- further sizes on request
- from 22 mm until 115 mm: ELORA-Chrome-Vanadium 31 CrV 3 / 1.2208
- from 120 mm until 165 mm: ELORA-Tempering steel C35 / 1.0501
- according to DIN 7444
Istilah Lain / Penyebutan
ring ketok, ring pukul
Measurements
| Number | Length mm | Weight g |
|---|---|---|
| 86-22 | 165 | 230 |
| 86-24 | 165 | 230 |
| 86-27 / 1.1/16 | 180 | 350 |
| 86-28 | 180 | 350 |
| 86-30 | 190 | 465 |
| 86-32 | 190 | 465 |
| 86-34 | 190 | 465 |
| 86-36 | 210 | 570 |
| 86-38 / 1.1/2 | 210 | 570 |
| 86-41 / 1.5/8 | 230 | 760 |
| 86-42 | 225 | 730 |
| 86-46 / 1.13/16 | 242 | 950 |
| 86-50 | 254 | 1120 |
| 86-55 | 268 | 1560 |
| 86-58 | 283 | 1625 |
| 86-60 | 283 | 1625 |
| 86-65 | 300 | 2130 |
| 86-70 | 330 | 2930 |
| 86-75 | 330 | 2800 |
| 86-80 | 360 | 4020 |
| 86-85 | 360 | 3900 |
| 86-90 | 390 | 5610 |
| 86-95 | 390 | 5610 |
| 86-100 | 420 | 6840 |
| 86-105 | 420 | 6450 |
| 86-110 | 445 | 8090 |
| 86-115 | 445 | 7610 |
| 86-120 | 480 | 10020 |
| 86-125 | 480 | 8600 |
| 86-130 | 510 | 13200 |
| 86-135 | 510 | 12900 |
| 86-140 | 520 | 13800 |
| 86-145 | 580 | 19200 |
| 86-150 | 580 | 18000 |
| 86-155 | 580 | 19200 |
| 86-160 | 580 | 19200 |
| 86-165 | 630 | 28600 |
