Electronic Side Cutter ESD
4530-...
Description
- for all work with electrostatic endangered components
- oval head, maximum stability under load by additional inductive hardening and box joint, with double opening leaf spring, polished and high gloss gunmetal-finish, with 2-C ESD handles, surface resistance 106-109 Ohm
- M= with bevel
- F= with fine bevel
- O= without bevel
- cutting edge hardness 61-63 HRC
- ELORA-high grade tool steel C60 / 1.0601
- DIN ISO 9654, ESD: DIN IEC 614340-5-1
Measurements
| Number | Hard mm / AWG | Medium mm / AWG | Soft mm / AWG | Length mm | Weight g |
|---|---|---|---|---|---|
| 4530-M E 2K | 0,4 / 26 | 1,0 / 18 | 1,5 / 15 | 125 | 95 |
| 4530-O E 2K | - | 0,8 / 20 | 1,5 / 15 | 125 | 98 |
