Combination Spanner with Joint-Ring Ratchet
204-R...
Description
- both ends fit same nut size
- 180° swivel-type ringside
- smallest possible swivel angle 5 °
- high torque transmission
- ground heads
- matt chrome plated
- using ELORA Adaptors No. 118-..., wrench will be usable as (bit-) ratchet
- ELORA-Chrome-Vanadium 31 CrV 3 / 1.2208
Measurements
| Number | Length mm | Weight g | More |
|---|---|---|---|
| 204-R 8 | 136 | 40 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 9 | 158 | 59 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 10 | 158 | 59 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 11 | 175 | 70 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 12 | 175 | 77 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 13 | 185 | 85 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 14 | 193 | 103 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 15 | 213 | 130 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 16 | 213 | 140 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 17 | 231 | 184 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 18 | 249 | 190 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
| 204-R 19 | 249 | 194 | PU:6 Productinformation: ELORA "ELO-Drive" Combination and Ring Spanners are equipped with the "ELO-Drive" profile on the ring side: higher torque on the flanks of the screws/nuts without damage of the same dynamic and safe working |
Produk Aksesoris
Produk Serupa
OMS-32
Module-Combination Spanner with Joint-Ring Ratchet
204-...
Combination Spanner with Ring Ratchet, metric
204-J...
Combination Spanner with Ring Ratchet, reversible
204RS12M
